Super functions
General
|
||
Frequency Range
|
136-174MHz; 400-470MHz
|
|
Channel Capacity
|
8 (TM-600) 128 (TM-610)
|
|
Zone Capacity
|
16 (TM-610)
|
|
Channel Spacing
|
25/20/12.5KHz
|
|
Operating Voltage
|
13.6V DC ±15%
|
|
Current Drain
|
Standby:
|
0.5A
|
Receive:
|
<2.0A
|
|
Transmit:
|
<5A(5W)/<8A (25W)
|
|
Frequency Stability
|
±2.5ppm
|
|
Antenna Impedance
|
50Ω
|
|
Dimensions (W×H×D)
|
152mm×43mm×125mm
|
|
Weight
|
1Kg
|
|
Transmitter
|
||
RF Power Output
|
5W /25W
|
|
Modulation
|
16K0F3E/11K0F3E
|
|
Spurious and Harmonics
|
-36dBm < 1GHz -30dBm > 1GHz
|
|
FM Noise
|
>45dB (25/20KHz) >40dB (12.5KHz)
|
|
Audio Distortion
|
≤3%
|
|
Receiver
|
||
Sensitivity
|
0.28/0.33/0.35 μV
|
|
Selectivity
|
75/70/65dB
|
|
Intermodulation
|
70/70/65dB
|
|
Spurious Response Rejection
|
70dB
|
|
S/N (wide/medium/narrow)
|
>45dB (25/20KHz) >40dB (12.5KHz)
|
|
Internal Audio Power Output (Rated)
|
5W (less than 5% distortion) 3W (less than 3% distortion)
|
|
External Audio Power Output (Rated)
|
13W (less than 5% distortion) 10W (less than 3% distortion)
|
