Ultra-slim TETRA Portable Radio

Z1p

Compact design and high transmitting power


The Z1p from Hytera combines a compact design with extensive TETRA functionality in a case that is only 23 mm thin. With its small dimensions, this handheld radio is perfectly suited for concealed carry. Despite its compact design Z1p transmits with up to 3 watts of power.


Two available case variants

The TETRA radio is available in two case variants. In addition to the variant with light alloy frame, the Z1p is available in a full plastic case. This black variant is 15 grams lighter.

Dustproof and waterproof in accordance with IP67

The Z1p offers excellent features even under harsh operating conditions. The device fulfills the requirements of degree of protection IP67 and can be submerged in water at a depth of 1 meter for at least 30 minutes. The Z1p meets the requirements of the American MIL-STD- 810 G-standard and has passed the HALT tests (Highly Accelerated Life Test).

Extensive security functions


TETRA security features such as air interface encryption and end-to-end encryption reliably protect the radio communication. On top of that, the Z1p can be programmed for user access with PIN and PUK, as well as with a password to protect the programmed information.



Intelligent antenna design


The integrated radio and GPS antenna provides high comfort and even better features. The two knobs on the Z1p are separated by the antenna to prevent operating errors, even when wearing gloves or in poor light conditions.



Immediate and direct communication


Z1p provides rapid access to the TETRA radio network and to its services. It was developed according to the regulations of the ETSI TETRA standard and is therefore compatible with infrastructures and terminals from various manufacturers.



Frequency Range 320-380MHz
380-430MHz
405-475MHz
806-870MHz
RF Power Output 3W(1.8W for 806-870MHz)
Battery 1400mAh(standard)
1800mAh(option)
Battery Life (5/5/90) >16.1 Hours(1800mAh)
>20.7 Hours(2500mAh)
Dustproof & Waterproof IP67
Dimensions(HxWxD) 120x58x23mm(1400mAh battery)
Weight 268g (with battery & antenna, silver)
255g (with battery & antenna, black)
