RD968
Smart Battery
Slim and Portable
Digital-analog Interconnection for Smooth Migratio
IP67
Smart Battery (optional)
Digital/analog Compatibility and Smart Switching
Back to back interconnection of digital & analog networks can be achieved by wired or wireless IP, ensuring a smooth analog -to-digital migration.
Flexible Networking
By connecting geographically distributed repeaters that run at the same or different frequencies to form an IP-based and location-independent wireless communication network, IP-based repeater interconnection allows mobile radios to obtain voice and data services while roaming.
16 Channels
The product supports up to 16 channels. You can switch between channels using PC-based RDAC software, the channel selector knob on the front panel, or the external interface on the repeater.
Digital-analog Interconnection for Smooth Transition
The feature enables two-way radios with digital and analog capabilities, and digital and analog users to intercommunicate in different operating modes to guarantee users' seamless transition from analog to digital capabilities.
The GPS module supports GPS data transmission and enables emergency command centers to monitor the location of a small mobile network in real time.
|
General
|
|||
|
Frequency Range
|
VHF 136-174MHz
UHF1 400-470MHz UHF3 350-400MHz |
||
|
Channel Capacity
|
16
|
||
|
Channel Spacing
|
12.5kHz/20kHz/25kHz
|
||
|
Operating Voltage
|
DC: 13.6 V±15% Battery: 14.8V
|
||
|
Current Drain
|
Standby
|
<0.5A
|
|
|
Transmit
|
<2.5A
|
||
|
Frequency Stability
|
±0.5ppm
|
||
| Battery | 10Ah（Li-lon） | ||
| Battery Life(50-50 Duty Cycle, High TX Power) | 8h | ||
|
Antenna Impedance
|
50Ω
|
||
|
Dimensions (H×W×D)
|
301x184x51mm (with protective shell)
291x172x41mm (without protective shell) |
||
|
Weight
|
<3.0kg
|
||
|
Transmitter
|
|||
|
RF Power Output
|
1-10W (adjustable)
|
||
|
FM Modulation
|
11K0F3E@12.5kHz
14K0F3E@20kHz
16K0F3E@25kHz
|
||
|
4FSK Digital Modulation
|
12.5kHz Data Only: 7K60FXD
12.5kHz Data & Voice: 7K60FXW
|
||
|
Conducted/Radiated Emission
|
-36dBm <1GHz
-30dBm >1GHz
|
||
|
Modulation Limiting
|
±2.5 kHz @ 12.5 kHz
±4.0 kHz @ 20 kHz
±5.0 kHz @ 25 kHz
|
||
|
FM Hum & Noise
|
40dB @ 12.5 kHz
43dB @ 20 kHz
45dB @ 25 kHz
|
||
|
Adjacent Channel Power
|
60dB@12.5kHz
70dB@20 /25kHz
|
||
|
Audio Response
|
+1 ~ -3dB
|
||
|
Audio Distortion
|
≤3%
|
||
|
Digital Vocoder Type
|
AMBE++ or SELP
|
||
|
Digital Protocol
|
ETSI-TS102 361-1,2&3
|
||
|
Receiver
|
|||
|
Sensitivity
|
Analog
|
0.3μV (12dB SINAD)
0.22μV (Typical) (12dB SINAD)
0.4μV (20dB SINAD)
|
|
|
Digital
|
0.3uV/BER5%
|
||
|
Adjacent Channel Selectivity
TIA-603
ETSI
|
65dB @ 12.5 kHz ；75dB @ 20/25 kHz
60dB @ 12.5 kHz ；70dB @ 20/25 kHz
|
||
|
Intermodulation
TIA-603
ETSI
|
75dB @ 12.5/20/25 kHz
70dB @ 12.5/20/25 kHz
|
||
|
Spurious Response Rejection TIA-603
ETSI
|
75dB @ 12.5/20/25 kHz
70dB @ 12.5/20/25 kHz
|
||
|
Blocking
TIA-603
ETSI
|
90dB
84dB
|
||
|
Hum and Noise
|
40dB @ 12.5KHz
43dB @ 20KHz 45dB @ 25KHz |
||
|
Rated Audio Distortion
|
≤3%
|
||
|
Audio Response
|
+1 ~ -3dB
|
||
|
Conducted Spurious Emission
|
<-57dBm
|
||
|
Environmental Specifications
|
|||
| ESD | IEC 61000-4-2 (level 4) ±8kV (contact) ±15kV (air) |
||
| American Military Standard | MIL-STD-810 C/D/E/F/G | ||
| Dust & Water Intrusion | IP67 Rating | ||
| Humidity | Per MIL-STD-810 C/D/E/F/G Standard | ||
| Shock & Vibration | Per MIL-STD-810 C/D/E/F/G Standard | ||
| GPS | |||
| TTFF (Time To First Fix) Cold Start | <1 minute | ||
| TTFF (Time To First Fix) Hot Start | <10 seconds | ||
| Horizontal Accuracy | <10 meters | ||
