UL913 and CSA Certificated Explosion-proof Safety
High Audio Quality and Assured Communication
Benefited from the latest digital DMR technology, PD788 ensures your workers talk and hear clearly over excessive noise.
Ease To Use
With large PTT, volume, channel knobs and programmable buttons, PD708 is easy to operate even when wearing gloves.
Larger Li-Ion Battery Capacity, Longer Cycle Life
Equipped with 2400mAH and UL913/CSA certificated Li-Ion battery, PD788 provides with shift life of 18 hours under 5-5-90 duty cycle. And the battery life-span becomes longer because the charge/discharge cycles are reduced.
Higher Spectrum Efficiency, Higher Channel Capacity
Benefiting from the TDMA technology, PD788 doubles the channel capacity based on the same spectrum resource. This is a big help to relieve the stress of increasing shortage in spectrum resource.
Dual Modes (Analog + Digital)
PD788 can operate in either analog or digital mode. It is compatible with the prevalent analog system, ensuring a smooth analog-to-digital migration.
Dual-slot Pseudo Trunk
With this feature, the free slot can be allocated to a member that needs to communicate, effectively enhancing frequency efficiency and allowing you to communicate timely under emergency situations.
Secure Communication
PD788 supports option board interfaces to radio, allowing third party partner to develop various applications to interconnect with radios to control the radio to expand its functionalities! Among the supported features are voice recording, encryption etc. Please refer to the API Partner Programmed for more information!
Dual Modes (Analog+Digital)
Besides the basic encryption of the digital technology, PD788 provides enhanced encryption capability (such as 40,128, 256-bit encryption algorithm) and the Scrambler feature (optional).
General
|
||
Frequency Range
|
UHF1: 400-470MHz; UHF2: 450-520MHz UHF5: 806-941MHz*; VHF: 136-174MHz |
|
Channel Capacity
|
1024
|
|
Zone Capacity
|
64 (each with a maximum of 16 channels) |
|
Channel Spacing
|
12.5KHz/20KHz/25KHz
|
|
Operating Voltage
|
7.4V (rated)
|
|
Battery
|
2400mAh (Li-Ion)
|
|
Battery Life (5-5-90 Duty Cycle, High TX Power) High-capacity 2400mAh Li-Ion Battery |
Analog: UHF1: 16h 14.5h (G);UHF2: 15.8h 14.4h (G);UHF5 : 16.8h 15.2h(G);VHF: 15.6h 14.2h (G) Digital: UHF1: 21.2h 18.8h (G);UHF2: 20.6h 18.3h (G);UHF5: 21.3h 18.9h(G);VHF: 20.6h 18.3h (G) |
|
Frequency Stability
|
±1.5ppm
|
|
Antenna Impedance
|
50Ω
|
|
Dimensions (H×W×D) (with standard battery, without antenna) |
125 X 55 X 43mm
|
|
Weight (with antenna & standard battery)
|
369g
|
|
Transmitter
|
||
RF Power Output
|
UHF1/UHF2 High Power:4W UHF1/UHF2 Low Power:1W UHF5 High Power: 3W (806-870MHz), 2.5W (896-941MHz); U5 Low Power: 1W VHF High Power:5W; VHF Low Power:1W |
|
FM Modulation
|
11K0F3E @ 12.5KHz 14K0F3E @ 20KHz 16K0F3E @ 25KHz |
|
4FSK Digital Modulation
|
12.5KHz Data Only: 7K60FXD 12.5KHz Data & Voice: 7K60FXW |
|
Conducted/Radiated Emission
|
-36dBm<1GHz -30dBm>1GHz |
|
Modulation Limiting
|
±2.5KHz @ 12.5KHz ±4.0KHz @ 20KHz ±5.0KHz @ 25KHz |
|
FM Hum & Noise
|
40dB @ 12.5KHz 43dB @ 20KHz 45dB @ 25KHz |
|
Adjacent Channel Power
|
60dB @ 12.5KHz 70dB @ 20/25KHz |
|
Audio Response
|
60dB @ 12.5KHz 70dB @ 20/25KHz |
|
Audio Distortion
|
≤3%
|
|
Digital Vocoder Type
|
AMBE++ or SELP
|
|
Digital Protocol
|
ETSI-TS102 361-1, -2,-3
|
|
Receiver
|
||
Sensitivity
|
Analog
|
0.3μV (12dB SINAD) 0.22μV (Typical) (12dB SINAD) 0.4μV (20dB SINAD) |
Digital
|
0.3μV /BER5%
|
|
Selectivity TIA-603 ETSI |
60dB @ 12.5KHz/70dB @ 20&25KHz 60dB @ 12.5KHz/70dB @ 20&25KHz |
|
Intermodulation TIA-603 ETSI |
70dB @ 12.5/20/25KHz 65dB @ 12.5/20/25KHz |
|
Spurious Response Rejection
TIA-603
ETSI
|
70dB @ 12.5/20/25KHz 70dB @ 12.5/20/25KHz |
|
Blocking
TIA-603
ETSI
|
80dB 84dB |
|
Hum and Noise
|
40dB @ 12.5KHz 43dB @ 20KHz 45dB @ 25KHz |
|
Rated Audio Power Output
|
0.5W
|
|
Rated Audio Distortion
|
≤3%
|
|
Audio Response
|
+1 ~ -3dB
|
|
Conducted Spurious Emission
|
< -57dBm
|
|
Environmental Specifications
|
||
ESD
|
IEC 61000-4-2(level 4) ±8kV (contact) ±15kV (air) |
|
American Military Standard
|
MIL-STD-810 C/D/E/F/G
|
|
Dust & Water Intrusion
|
IP67 Standard
|
|
Humidity
|
Per MIL-STD-810 C/D/E/F Standard
|
|
Shock & Vibration
|
Per MIL-STD-810 C/D/E/F Standard
|
|
GPS (for PD78XG only)
|
||
Accuracy specs are for long-term tracking(95th percentile values>5 satellites visible at a nominal -130dBm signal strength)
|
||
TTFF (Time To First Fix) Cold Start
|
<1 minute
|
|
TTFF (Time To First Fix) Hot Start
|
<10 seconds
|
|
Horizontal Accuracy
|
<10 meters
|
